KRJ-320DNL Gigabit ethernet connector RJ45 with isolation transformer Moudles for Internet Camera

Name: KRJ320DNL Gigabit ethernet connector RJ45 with isolation transformer Moudles for Internet Camera
Brand: DGKYD
Price: 1 USD

Wholesale KRJ-320DNL Gigabit ethernet connector RJ45 with isolation transformer Moudles for Internet Camera from china suppliers

Place of Origin : DongGuan of China

Brand Name : DGKYD

Certification : RoHS/CE/UL/FCC/CE/ISO9001/ISO14001

MOQ : 1 piece

Packaging Details : Tray in Carton

Delivery Time : 10 days

Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram

Supply Ability : 100K pcs/day

Model Number : KRJ-320DNL

Price : Please contact us to get the latest price.

Product Name : RJ45 with Transformer

Type : RJ45 Female

Housing : Phenolic, PBT Black (UL94V-0)

Plastic core : Glass fiber filler PBT Black(UL94V-0),ROHS

Shield RJ45 : yes

No.Port : RJ45 single port

Operating temperature : - 40℃～85℃

Number of pins : 10

Shield : phosphor copper nickel plating

Gold plating on contact pins : 6U

Contact Now

KRJ-320DNL Gigabit ethernet connector RJ45 with isolation transformer Moudles for Internet Camera

Product Specification Document

KRJ-320DNL.pdf

Part Number	KRJ-320DNL	Brand	DGKYD/OEM/ODM
Product Type	Connector-Modular	Connector Style	Jack
Jack Type	RJ45	Connector Type	Modular Jack
Latch Style	Standard	Latch	TAB-down
Filter	With Filter	LED Option	With LED
LED Color	Green/Yellow	Panel Stops	Without Panel Stops
Shielded	With metal shield	Applies To	Printedout Circuit Board
Port Configuration	1X 1 Ports	Number of Positions	10
Jack Configuration	1 x 1	Terminals per Port	8
Shield Material	Copper Alloy preplated with Nickel	PCB Mounting Orientation	Side Entry (Right Angle)
Contact Mating Area Plating	Gold 6u	Contact Base Material	Phosphor Bronze
Solder Tail Contact Plating Material	Tin-Lead over Nickel	PCB Mounting Style	Through Hole
Termination Method to PC Board	Through Hole-Press-Fit	Board Lock	With/Without Board Lock
Housing Material	PBT Polyester	Housing Color	Black
Housing Material Temperature	Standard	UL Flammability Rating	UL 94V-0

Applications:

Integrated RJ45 connector main used to :

• 10/100/1000M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,

optical transceiver,IP phone, internet set-top box,internet camera,net bridge,

computer,telecommunication,MODEM,HomePNA,DSL／ADSL and so on.

For example:

KRJ-320DNL Gigabit ethernet connector RJ45 with isolation transformer Moudles for Internet Camera

Competitive Advantage:

Keyouda has various types of appearance and many kinds of internal schematic products,high quality,

customer firstly ,100% test, 0 defect, short lead time are our best advantages
